Maximize Your Energy Efficiency
Designed to operate at high levels of efficiency up to 92%, with 2000W continuous power and 4000W surge power. It converts the 12VDC to 110VAC power with minimal loss of energy, helping to reduce your overall power consumption and extend your battery life.
ECO Power-Saving Mode
The integrated ECO Power-Saving Mode automatically adjusts the power output according to the amount required by your devices, thereby reducing overall power consumption and ultimately prolonging the lifespan of your battery.
Smart Monitoring Ready
Unlock monitoring features with the BT-2 Module and Renogy DC Home App, available on IOS and Google Play Store. Monitoring Screen ready when combined with the RMS-PGH for monitoring and remote power control.
Reliable Power Output
The inverter delivers a pure sine wave output, which ensures clean and stable power for sensitive electronic devices, including laptops, TVs, and smartphones. It is essential for ensuring that your devices operate efficiently and safely.
Extremely Low Self-Consumption
The new 2000 watt pure sine wave inverter consumes very little power when not in use. This is important because inverters can drain your battery even when they are not supplying power to your devices. With the low self-consumption rate of the Renogy inverter, you can be sure that your battery will last longer, and you will save energy and money in the long run.
High-Speed Ventilation Fans
This solar inverter comes with two high-speed ventilation fans that help to dissipate heat and maintain stable operating temperatures even under heavy loads.
DESCRIPTION
【Maximize Your Energy Efficiency】 Designed to operate at high levels of efficiency up to 92%, with 2000W continuous power and 4000W surge power. It converts the 12VDC to 110VAC power with minimal loss of energy, helping to reduce your overall power consumption and extend your battery life.
【ECO Power-Saving Mode】 The integrated ECO Power-Saving Mode automatically adjusts the power output according to the amount required by your devices, thereby reducing overall power consumption and ultimately prolonging the lifespan of your battery.
【Smart Monitoring Ready】 Unlock monitoring features with the BT-2 Module and Renogy DC Home App, available on IOS and Google Play Store. Monitoring Screen ready when combined with the RMS-PGH for monitoring and remote power control.
【Reliable Power Output】 The inverter delivers a pure sine wave output, which ensures clean and stable power for sensitive electronic devices, including laptops, TVs, and smartphones. It is essential for ensuring that your devices operate efficiently and safely.
【Extremely Low Self-Consumption】 The new 2000 watt pure sine wave inverter consumes very little power when not in use. This is important because inverters can drain your battery even when they are not supplying power to your devices. With the low self-consumption rate of the Renogy inverter, you can be sure that your battery will last longer, and you will save energy and money in the long run.
【High-Speed Ventilation Fans】 This solar inverter comes with two high-speed ventilation fans that help to dissipate heat and maintain stable operating temperatures even under heavy loads.
The new Renogy 2000W 12V Pure Sine Wave Inverter with Power Saving Mode converts DC power stored in batteries into standard household AC power on-the-go. With a power output of up to 2000 watts, this solar inverter is perfect for powering a wide range of devices and appliances, including computers, TVs, power tools, and more. Its pure sine wave output delivers clean and stable power, ensuring your devices run smoothly and efficiently. The 12V power inverter also comes with a built-in power-saving mode, which helps to conserve energy by automatically adjusting the power output based on the load, reducing your overall power consumption and saving you money on your energy bills. The 2000 watt inverter is monitoring ready when combined with the BT-2 Module and Renogy DC Home App, or RMS-PGH Monitoring Screen.
NOTE
- If you have any questions regarding this product, please call us at 1 (909) 287-7111 or or contact us with livechat for troubleshooting assistance.
- More questions about your off-grid power system? Learn more from Renogy Learning Center!
NOTE
- If you have any questions regarding this product, please call us at 1 (909) 287-7111 or or contact us with livechat for troubleshooting assistance.
- More questions about your off-grid power system? Learn more from Renogy Learning Center!
Package Includes
|
2000W 12V Pure Sine Wave Inverter with Power Saving Mode
1 x
|
Inverter Remote Control
1 x 16.4Ft
|
Inverter Cables
2 x 4AWG
|
2000W 12V Pure Sine Wave Inverter with Power Saving Mode (New Edition)
GENERAL DATA
Output Waveform:
Pure Sine Wave
AC Terminals:
2 x AC Sockets + Terminal Block
DC Terminals:
M8-1.25x15
Communication:
RS485
Operating Temperature:
-4°F -104°F/-20°C - 40°C
Storage Temperature:
-40°F-158°F/'﹣40℃～70℃
Humidity:
Max 93%, Non-condensing
Cooling:
Thermally Controlled Fans
Dimensions (LxWxH):
15.8 x 9.8 x 3.8in / 401 x 249 x 96mm
Weight:
10.4 lbs / 4.7 kg
ELECTRICAL DATA
Continuous Output Power:
2000W
Continuous Output Current:
8.3A AC
Total Harmonic Distortion (THD):
< 3% Linear Load / < 5% Non-linear Load
Power Factor:
＜1
Surge Rating:
4000W (@ 1s)
Output Voltage:
120Vac±10%
Output Frequency (Configurable):
50Hz /60Hz
Rated Battery Input Voltage:
12VDC
Battery Input Voltage Range:
11VDC~16.5VDC
Maximum Continuous Battery Input Current:
166.6A
Inverter Efficiency:
>92%
Full Load Efficiency:
>89%
Power Consumption:
<10W
ECO Power Consumption:
＜5W
Battery Overoltage Shutdown:
16.5VDC
Battery Low Voltage Alarm:
10.5VDC
Battery Low Voltage Shutdown:
10VDC
opc:
WIRED REMOTE DATA
Overall Dimensions:
2.8x4.3x1.3 in /70x110x31.8mm
Wired Length:
16.40ft
FAQ
1.Can the 2000 watt model be mounted vertical?
Never because of the potential of block cooling fans.
2. What’s the difference in features between this one and the old 2000?
It has a switch to change from 60hz to 50hz.
3. Can these be used in parallel?
Yes, but it would probably be cheaper to purchase the 2000 watt or 3000 watt inverter.
4. How low of a battery charge will this 2000 W inverter continue to supply power? The one I have now quits if the batteries drop below 11.7 volts. ?
The problem with your current inverter is most likely poor or too small or too long of a wire between the batteries and the inverter. When you have a high resistance in the wiring, and the inverter is drawing a high load, the voltage "seen" by the inverter is lowered.
5. What is the load and no load current draw in watts for the 2000w inverter?
At power (P)=2000 watts divided by system voltage (V) ie. 120 volts, max Load in Ampere = 16.6A. Recommended 15 amp load.
6. What size inverter should I buy?
1. Sizing the right power output. Inverters will be rated by a wattage value, telling you how many watts it can run at one time. For example, imagine you had a 500 Watt Fridge and 800 Watt Air Conditioning. These two items would be 1300 Watts and would require an inverter with a higher wattage than 1300W. Renogy 2000W and 3000W inverter will meet your power needs. 2. Check your battery voltage. The DC voltage rating on the inverter will tell you what battery bank it is compatible with. For example, a 12V battery bank will require an inverter that is compatible with 12V DC input. 3. Size your installation spaces. What area or space will you set your inverter? Make sure the inverter will fit in the space you have in mind with enough room around it for proper ventilation and no fire hazards. 4. Remote operation is important. Renogy pure sine inverters come with convenient remote control and DC HOME APP options so that you can operate the unit from afar.
7. Do I need Modified Sine Wave, or Pure Sine Wave?
Modified sine wave inverters are older technology and generally less expensive. They can be used for many standard appliances but may cause trouble with delicate electronics or audio equipment. Some equipment may work but run hotter than normal. Pure sine wave inverters are a bigger investment, but much more versatile. a) Output voltage wave form is pure sine wave with very low harmonic distortion and clean power like utility-supplied electricity. b) Inductive loads like microwave ovens and motors run faster, quieter and cooler. c) Reduces audible and electrical noise in fans, fluorescent lights, audio amplifiers, TV, Game consoles, Fax, and answering machines. d) Prevents crashes in computers, weird print out, and glitches and noise in monitors.
8. Can I use the Bluetooth Module to monitor the inverter from my phone? Which Bluetooth Module should I buy?
Yes, Bluetooth monitoring is supported. If necessary, you can acquire the BT-2 Bluetooth module for monitoring through either the DC Home app or Renogy One M1/Core Monitor.
